Magnetic cable connector square 2pin male and female electrical pogo pin

브랜드 이름:	UPE
모델 번호:	VID0060A/VIC0200C
모크:	5000
가격:	$1-$5
포장 세부 사항:	PE 가방
지불 조건:	t/t

자세한 정보

제품 설명

자세한 정보

원래 장소:

중국

인증:

ISO9002

문서:

VID0060A.pdf

이름:

자기 케이블 커넥터

케이블 길이:

1000mm

색상:

검은색

자기력:

550g

기계적 수명:

50000 사이클 분

재료:

TPE, 황동

전단력:

80g ± 20g

일하는 Storke:

1.0mm

현재의:

3.0A

휘장:

12V

작동 온도 ::

-25℃ ~ +60℃

접촉 저항:

50mΩ 최대 (PIN)

공급 능력:

5KPCS/일

강조하다:

magnetic cable connector 2pin

square pogo pin connector

male female magnetic connector

제품 설명

Magnetic Cable Connector Square 2Pin Male and Female Electrical Pogo Pin

UPE is a professional magnetic connector & magnetic cable connector manufacturer. We have our own professional designers to meet any of your requirements and provide magnetic connector customization service. Different magnetic pogo pin connector products and solutions can be designed according to different customer needs.

Material and coating conform to ROHS and REACH standards.

Materials

The metal needle part is plated with gold on the brass surface
The hard plastic material is made of HTN+30%UL94 V-0 black, which can withstand high temperatures
The magnet adopts high-performance permanent magnet neodymium iron boron
Black TPE 80A outer mold of the joint
Wire OD3.5mm 2C(red and black: 65*0.08)
Covered with black TPE
USB: stainless steel shell USB2.0

Mechanical Properties

Spring force: 80g ±20g at 1.0 working height
Service life: 50,000 times minimum

Electrical Properties

Reference voltage: 12V
Continuous working current: 3.0A
Maximum momentary current: 4.0A maximum
Contact static impedance of the needle: 50mΩ Max (PIN)

Product Features

Adopts environmental protection materials, ROHS, REACH compliant
The adhesive force of the magnetic male and female docking is more than 550G
Product anti-short-circuit structure design
Polarity and electrical direction are clearly identified

2Pin Male Magnetic Cable Connectors & Magnetic Connector Parameters

Name	Magnetic Cable Connector
Type	Male/Female
Pin	2pin
Cable	TPE
Cable length	1000mm
Color	Black
Pogo pin	Brass 0.125 um Au over 1.5um~2.5um Ni
Female pin	Brass 0.125 um Au over 1.5um~2.5um Ni
Shell	SUS304
Insulator	Black High Temperature Resistant Plastics
Magnet	NdFeB N52 1.5um~2.5um Ni
Spring force	80g±20g, at 1.0mm working stroke
Mechanical life	50000 cycle Min.
Magnetic force	550g
Current	3.0A Max
Voltage	DC12V
Contact resistance	50mΩ Max (PIN)
Operation Temperature	25℃ to +60℃
Salt spray test	24H
Certification	ROHS or REACH compliant product
Test	100% open and short test

2Pin Magnetic Cable Connector Technical Drawing

2Pin Magnetic Connector Technical Drawing

Advantages of Magnetic Connector

● Humanize design of automatic adsorption connection experience

● Humanized anti-fall: it is easy to remove from the charging interface, and it is not easy to remove the device

● Life time: up to 100,000-200,000 cycle

● Waterproof design: the female end of the device can be dustproof and waterproof (IPX8)

● Fast charging time: 5A-10A magnet connector design withstands large current transmission

● The appearance of the magnetic connector can be matched according to the design of the customer's application device

● Product anti-short circuit structure design and foolproof

● Realize high frequency signal transmission, can replace the traditional USB2.0 HDMI 1.3 function Video&Audio signal transmission

Magnetic Connector Products Application

Wearable devices, intelligent positioning equipment, children's smart wristbands, smart watches, wearable mobile phones, Bluetooth headsets, etc.) data cable, charging cable, magnetic strip wire end connection
Medical equipment, wireless equipment, data communications equipment, telecommunication equipment, Automation and industrial equipment, audio-visual equipment
Aviation, aerospace electronic, military communication
Automotive, car navigation, test and measurement equipment
Consumer Electronics (mobile phones, tablet computers, Bluetooth headsets, camera, watch, portable consumer electronic products and many other electronic fields.)

Why UPE Shall Be Your Partner?

1. Specialized Expertise in Magnetic Connectors

Focused R&D: UPE has dedicated experience in magnetic connectors
Customization: UPE can tailor magnet strength, pin plating (gold/nickel for ≤50mΩ resistance), and housing materials (black PBT/nylon) to your needs

2. High Durability & Compliance

10,000+ Cycles Guaranteed: Their connectors likely undergo rigorous testing to meet your mechanical life demand
Certifications: Compliant with UL, or RoHS standards--critical for consumer/medical markets

3. Competitive Manufacturing

Cost-Effective Tooling: UPE may offer low MOQs (e.g., 1K-5K units) with competitive pricing for small-to-medium batches
Quality Control: In-house testing for contact resistance, pull force, and current load to ensure reliability

4. Fast Prototyping & Support

3D Samples in Days: Rapid prototyping for fit/function checks
Engineering Support: Assistance with pinout optimization, EMI shielding, or waterproofing (IP68)

How to Place Your Magnetic Cable Connector Order with UPE

1. Submit Your Requirements

Contact our sales team via:
Email: union@upetech.net
Phone: +86 13434524996
Online Form: www.pogopinsconnector.com

Provide details:
✔ Application (e.g., medical, automotive, consumer electronics)
✔ Connector type (e.g., magnetic pogo pin, charging cable)
✔ Specifications (voltage, current, size, waterproof rating, etc.)
✔ Quantity & lead time

2. Get a Custom Solution (If Needed)

Our engineers will review your needs and propose a custom design (if required).
We'll share 3D models, samples, or technical drawings for approval.

Payment Term

50% Deposit (Paid upfront): Covers production costs (materials, labor).
50% Balance (Paid before shipment): Ensures quality control and commitment from both parties.

Payment Method

T/T (Bank Transfer), PayPal, OCBC Bank
Recommendation:
Use PayPal for samples (safer).
Use T/T for bulk orders (lower fees).

Lead Times

Sample Lead Time: Inventory sample 2-3 Working day/customized sample 5-7 Working day
Production Lead Time: 10-15 Working day
Made For: America, Europe, Asia, South African
Trade Term: EXW
Freight: Air, Sea, Express
Service: High quality with reasonable price, OEM service, any special size, color, designs are acceptable
