| 이름: | 솔더 컵 스프링로드 포고 핀 | 소재: | 황동 C3604, SUS304 |
|---|---|---|---|
| 전류: | 3A | 전압: | 12V |
| 기계적 생명: | 50000 사이클 최소 .. | 콘택 저항: | 50mΩ 최대 작업 높이 |
| 작동 온도: | -40+~+130 ℃ 24 시간 내에. | 염수 분무 시험: | 48 Ｈ |
Screw-type: The products with special specifications can meet the different needs of customers, and can be customized according to the needs
of customers.
One-piece type: It can pass large currents, be customized according to customer requirements, and meet different customer needs.
Spherical ball type: Lateral force is available, and it can be customized according to customer requirements to meet different customer needs.
UPE Pogo Pin Internal Structure according to customer requirements to match suitable one
A.Structure description:Plunger for oblique bevel
B.Structure description:Plunger for drilled
C.Structure description:Plunger for flat
D.Structure description: Barrel inside added insulating beads
E.Structure description: Both sides of the plunger can be compressed
F.Structure description: Four-piece combination
G.Structure description: Intermediate shaft compression
H.Structure description: Ball compression contact
Pogo Pin application areas are:
Why do customers choose UPE?
1.Customization & Flexibility
2.Fast Samples = Faster Time-to-Market
3.Every connector undergoes rigorous quality checks( Incoming Material Inspection,In-Process Quality Checks,100% Final Testing,Traceability & Compliance)
4.Customer-Focused QC Flexibility
5.Real-Time QC Collaboration
Spring-Loaded Pogo Pin Connector parameter performance
|
Name of Parts |
Parameter performance table |
|||
|
Barrel Materia |
Brass |
Beryllium copper |
Phosphor Bronze |
|
|
Plunger Material |
Brass |
Beryllium copper |
Phosphor Bronze |
Stainless steel |
|
Spring options |
Stainle |
Music wire |
|
|
|
Plating requirements |
Gold-Au
|
Silver-Ag
|
Palladium-Nickel (Pd-Ni) |
|
|
Rated Current |
1A, 2A, 3A ,5A,15A or 30A (different structures) |
|||
|
Rated Voltage |
DC 12V 24V |
|||
|
Contact Resistance |
30mΩ 50mΩ Max. (stillness) |
|||
|
Life test |
50,000 cycles Min. 1000,000 cycles Max |
|||
|
Reflow Temp. |
265°, 4~5sec |
|||
|
POGO PIN Reliability Test |
||||
|
Retention Force |
At rated cycling of 500±50 per hour,50,000 cycles minimum |
|||
|
Humidity |
EIA-364-31,Test method II, Condition A Subject mated connectors to relative humidity of 90% to 95%RH and a temperature of 40℃ ± 2℃ relative humidity for 96 hour. |
|||
|
Resistance to Solder Heat
|
EIA-364-56,Procedure 5,Level 2 265℃+10/-0℃for 30 to 35 seconds
|
|||
|
Salt Spray
|
EIA-364-26,Test condition B Subject mated connectors to 5±1% salt-solution concentration, 35+1℃/-2℃ for 48 hours. |
|||
|
Spring force test
|
Normal Force Test Procedure,100g±20g at working height
|
|||
|
Temperature Life
|
EIA-364-17,Test method A,condition 4,Test time condition A Subject mated connectors to 85℃± 2℃ for 96 hours. |
|||
|
Solderability
|
EIA-364-52 Dip into the 265±5℃, 60/40±5% Sn/pb solder for 4.0~5.0 second |
|||
|
Contact Resistance
|
EIA-364-23 Measure the contact resistance with a test current of 100 mA maximum and 20 mV voltage maximum |
|||
Testing equipment:
We have an independent laboratory and equipped with relevant experimental equipment, such as
Insertion force testing machine, Two-dimensional projector, Thickness meter, Automatic inspection machine, Insulation Resistance Tester
Metallographic sample polishing machine, Salt spray tester, Current temperature rise tester, Load stroke curve instrument, Automatic inspection machine, ROHS tester, Roughness tester,Elastic impedance tester, Life tester, etc.
UPE Company’s Competitive Advantages:
1. High-Technology Production
Utilizes advanced manufacturing techniques for superior product quality.
2. Systematic Management System
Streamlined processes ensure efficiency and consistency in production.
3. ISO 9001 Certification
Demonstrates commitment to international quality management standards.
4. RoHS Compliance
All products meet Restriction of Hazardous Substances (RoHS) regulations, ensuring environmental and safety standards.
5.Short Development Lead Time
Faster prototyping and production cycles, enabling quicker market delivery.
6. Competitive Pricing & Stable Quality
Cost-effective solutions without compromising on reliability.
Payment method:
T/T (Bank Transfer),PayPal ,OCBC Bank
Recommendation:
Use PayPal for samples (safer).
Use T/T for bulk orders (lower fees).
Sample Lead Time: Inventory sample 2-3Working day/customized sample 5-7Working day
Production Lead Time:10-15Working day
Made For: America,Europe,Asia,South African
Trade Term: EXW
Freight: Air,Sea,Express
Service: High quality with reasonable price, OEM service, any special size, color, designs are acceptable
